SD-SDI Waveform Rasterizer with 2 Passive Loopthrough Inputs, one AES/EBU Audio Input, 16 CH of Embedded Audio Support, and Power Option "A0".

The WVR4000 Compact Video Rasterizer provides an ideal solution for basic video and audio monitoring needs in a convenient 1 RU half-rack form factor, suitable for space-constrained environments. This versatile instrument provides options to accept power from a 12 V DC source or a 100-240 V AC converter. Comes standard with support for 16 channels of Embedded Audio and 1 input for 2 channels of Digital AES Audio.

The Tektronix WVR4000 supports SD-SDI (ITU-R BT.601) monitoring only.

Features:

• Convenient 1 RU Half-rack Instrument, Ideal for Space-constrained Environments
• AC and DC Power Options
• Patented Gamut Displays Facilitate Compliance Verification
• TandemVu? Display for Efficient Camera Adjustments
• Error Log for 10,000 Events Simplifies Error Correction Tasks
• Fully Digital Processing for Accurate, Repeatable, Drift-free Operation
• Ethernet Port allows for Easy Download of Screenshots and Error Log
• Freeze Mode for Trace and Picture Displays
• Equipped Standard with Monitoring Capacity for 16 Channels of Embedded Audio (up to 8 Simultaneously) and 1 AES Audio Input
• Front-panel Headphone Port for Easy Monitoring of Audio Channels
• Audio Bars and Lissajous Displays for Verification of Audio on the Same Instrument
• 32 User-configurable Presets for Quick Recall of Commonly Used Configurations
• User-definable Safe Area Graticules Facilitate Editing Tasks
• Patented Tektronix Timing Display Makes Facility Timing Easy
• Picture Thumbnail with Line-select Marker
• Intuitive User Interface, Backlit Buttons, and Online Help
• High-resolution DVI-I Output for Crisp, Easy-to-Read Displays
• Passive Loopthrough Inputs for Transparent Monitoring at any Point of the Signal Path even when Instrument Power is Off
• Front-panel USB Port for Easy Transfer of Instrument Presets and Screenshots
• SNMP Control for Easy Systems Integration
